Precision Motion Products

Explore motors, actuators, drives and integrated motion solutions engineered for compact installation, dependable control and application-specific performance.

Explore Our Product Portfolio

SPHYC6022032-10-V-01 60 mm large-bore hollow shaft stepper motor

SPHYC6022032-10-V-01 60 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
32 mm
Holding Torque
0.17 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC6022032-10-V-01 is a 60 mm two-phase hollow shaft stepper motor with a 32 mm through bore, 20 ±0.5 mm body length, 1.8° step angle and 0.17 N·m holding torque.
SPHYC6022032-10-H-01 60 mm large-bore hollow shaft stepper motor

SPHYC6022032-10-H-01 60 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
32 mm
Holding Torque
0.17 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC6022032-10-H-01 is a 60 mm two-phase hollow shaft stepper motor with a 32 mm through bore, 20 ±0.5 mm body length, 1.8° step angle and 0.17 N·m holding torque.
sphyc5022922 12 h 01 hollow shaft stepper motor

SPHYC5022922-12-H-01 50 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
22 mm
Holding Torque
0.22 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC5022922-12-H-01 is a 50 mm two-phase hollow shaft stepper motor with a 22 mm through bore, 29 ±0.5 mm body length, 1.8° step angle and 0.22 N·m holding torque.
sphyc5022222 12 h 01 hollow shaft stepper motor

SPHYC5022222-12-H-01 50 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
22 mm
Holding Torque
0.11 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC5022222-12-H-01 is a 50 mm two-phase hollow shaft stepper motor with a 22 mm through bore, 1.8° step angle and 0.11 N·m holding torque.
SPHYC4021916-10-V-01 40 mm large-bore hollow shaft stepper motor

SPHYC4021916-10-V-01 40 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
16 mm
Holding Torque
0.045 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC4021916-10-V-01 hollow shaft stepper motor is a 40 mm two-phase large-bore design with a 16 mm through bore, 1.8° step angle and 0.045 N·m holding torque.
sphyc4021916 10 h 01 40 mm large bore hollow shaft stepper motor

SPHYC4021916-10-H-01 40 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
16 mm
Holding Torque
0.045 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SPHYC4021916-10-H-01 hollow shaft stepper motor is a 40 mm two-phase large-bore design with a 16 mm through bore, 1.8° step angle and 0.045 N·m holding torque.
SP50H 50 mm large-bore hollow shaft stepper motor

SP50H 50 mm Large-Bore Hollow Shaft Stepper Motor

Hollow Bore Diameter
22 mm
Holding Torque
0.22 N·m
Radial & Axial Runout
0.025 / 0.075 mm max
The SP50H is a 50 mm two-phase large-bore hollow shaft stepper motor with a 22 mm through bore, 1.8° step angle and 0.22 N·m holding torque.
SPIM86 86 mm multi-turn absolute stepper motor

SPIM86 86 mm Multi-Turn Absolute Stepper Motor

Supply voltage
18–70 VAC / 24–100 VDC
Holding torque
4.5–12.5 N·m
Communication
RS-485 / CANopen
Frame size
86 mm
Integrated 86 mm battery-free multi-turn absolute stepper motor with 1599-turn feedback, 18–70 VAC or 24–100 VDC operation, and Modbus/RS485 or CANopen communication.

Find the Right Motion Solution

Share your load, speed, travel, accuracy, duty cycle and environment requirements. Our application engineers will help you evaluate and select the right configuration.

Start with your application requirements. Share your load, speed, travel, accuracy, duty cycle and operating environment. Our engineers will recommend a practical motor, actuator and drive configuration.
Talk to an Engineer
Validate the critical operating points. We review mechanical load, motion profile, thermal limits, interfaces and installation constraints, then support samples and prototype testing before production.
Discuss Your Application

Why Engineers Choose Spotlight Motor

Precision

Application-matched motors and actuators support repeatable positioning, stable low-speed control and consistent production performance.

Compact Integration

Compact mechanics, integrated drives and configurable interfaces reduce installation space, wiring and commissioning effort.

Reliable Operation

Components are selected and validated around real duty cycles, thermal limits and environmental demands for dependable long-term operation.

Engineering clarity for confident motion system decisions.

Engineering support from selection to validation

We connect product selection, mechanical integration, drive configuration and application testing in one practical engineering workflow.

Application-ready technical data

Access dimensions, electrical parameters, interface definitions and available CAD resources for efficient system design.

Direct application engineering

Work directly with engineers to match motor, actuator and drive configurations to load, speed, travel, accuracy and duty-cycle requirements.

Flexible system integration

Choose from configurable mechanical, electrical and communication options to fit your machine architecture.

Performance validation

Confirm critical operating points through samples, prototype testing and application review before production.

Motion solutions built around your application

Spotlight Motor develops and supplies compact motors, linear actuators, drive systems and integrated motion solutions for industrial automation, medical instruments, semiconductor equipment and demanding scientific applications. Our focus is practical: reliable performance, clear engineering data and responsive collaboration from concept through production.
