Compact coreless motors and linear actuators for space-limited motion systems. Explore available frame sizes, drive configurations and mechanical output options using product-level technical data.
Open a family to review the products and technical information currently available for that category.
SP17H50 is a 42 mm 0.72° five-phase stepper motor with single-shaft construction, 0.3–0.5 N·m holding torque and 1.8 A/phase rated current.
SP17H50 is a 42 mm 0.72° five-phase stepper motor with double-shaft construction, 0.3–0.5 N·m holding torque and 1.8 A/phase rated current.
SP24H5055-240-5AC-FB is a 60 mm 0.72° five-phase stepper motor with a 24 V, 2 N·m brake and separate 500 mm motor and…
SP24H50 is a 60 mm 0.72° five-phase stepper motor with double-shaft construction, 1.15–2.1 N·m holding torque and 2.4 A/phase rated current.
SP24H50 is a 60 mm 0.72° five-phase stepper motor with single-shaft construction, 1.15–2.1 N·m holding torque and 2.4 A/phase rated current.
Compact 15 mm permanent magnet linear actuator with an 18° step angle, 0.5 or 1.0 mm lead, and fixed-nut or external-drive options…
The SP10ZWWC26 is a 10 mm brushless coreless DC motor rated at 12 V, 1.5 mN·m and 28,500 rpm for compact high-speed…
The SP12ZWWC29 is a 12 mm brushless coreless DC motor rated at 6 V, 4 mN·m and 12,000 rpm for compact precision…
Start with the operating environment and motion requirement, then confirm mechanical fit and electrical integration against the product-level technical data.
Define vacuum level, temperature range, cleanliness and other environmental constraints.
Confirm load, speed, torque, travel, positioning accuracy and duty cycle.
Match frame size, mounting interface, shaft or screw configuration and available installation space.
Review supply, current, feedback, drive method and communication requirements before selection.
Share your required motor type, operating environment, quantity and technical requirements. Our engineering team will review the details and contact you.
